Efficient flat flexible rvvb cable
The products comply with GB, IEC, DIN, ASTM, JIS, NF, as / NZS, CSA gost and other standards.
Description
Model | HZ-05B | Brand | OEM |
Product name | Efficient flat flexible rvvb cable | Type | Solid |
Application | Electronic equipment wiring | Place of Origin | Zhejiang,China(Mainland) |
Conductor Material | Copper | Voltage Rating | 300/500V |
Insulation Material | PVC | Transport Package | Carton |
Core number | single and multi core | certificated | ISO9001、CE、UL、CCC、RoHS |
Application and Features
Efficient flat flexible rvvb cable is pvc insulated and sheathed cable， applicable to the internal wiring of electrical appliances, instruments, distribution boards and distribution boards or where solid core wires are required. It is suitable for fixing and flexible laying in dry rooms. Can be used for exposed and embedded conduits. It is used in electronic and electrical equipment and switchgear exported to European countries, and MRO is used to replace equipment wires made in Europe.
pvc insulated pvc sheathed cable is suitable for fixed wiring or flexible connection of power supply devices and electrical appliances with rated voltage of 300 / 500V and 450 / 750V, such as lighting, electronic equipment, instruments and communication equipment. Working temperature: the allowable working line shall not exceed + 70 ℃ for a long time.
Product
Technical Data
Nominal Sectional Area | No. and Diameter of wire | Thickness of Section Sheath | Overall Diameter | Max.Conductor Resistance at 20ºC | Reference Weight | ||
Min. | Max. | YH | YHF | ||||
m | mm | mm | mm | mm | ≤Ω/km | kg/km | kg/km |
10 | 322/0.20 | 1.8 | 7.5 | 9.7 | 1.91 | 146 | 153.51 |
16 | 513/0.20 | 2.0 | 9.2 | 11.5 | 1.16 | 218.9 | 230.44 |
25 | 798/0.20 | 2.0 | 10.5 | 13.0 | 0.758 | 316.6 | 331.15 |
35 | 1121/0.20 | 2.0 | 11.5 | 14.5 | 0.536 | 426 | 439.87 |
50 | 1596/0.20 | 2.2 | 13.5 | 17.0 | 0.379 | 592.47 | 610.55 |
70 | 2214/0.20 | 2.4 | 15.0 | 19.5 | 0.268 | 790 | 817.52 |
95 | 2997/0.20 | 2.6 | 17.0 | 22.0 | 0.198 | 1066.17 | 1102.97 |
120 | 1702/0.30 | 2.8 | 19.0 | 24.0 | 0.161 | 1348.25 | 1392.55 |
150 | 2135/0.30 | 3.0 | 21.0 | 27.0 | 0.129 | 1678.5 | 1698.72 |
185 | 1443/0.40 | 3.2 | 22.0 | 29.0 | 0.106 | 1983.8 | 2020.74 |
Our Company
Packaging
FAQ
Q1.What certificate did you get?
A: We have CCC, CE, VDE, IMQ and other certificates.
Q2.What is the delivery time for mass production?
A: To be honest, it depends on the number of orders and the season you place your order. In general, we recommend that you start your inquiry two months before the date you want to obtain products in your country.
Q3.What can you offer?
A: We produce all kinds of wires and single core insulated and sheathed cable which can be customized according to your requirements.
Q4.How can I get samples to check your quality?
A: After the price is confirmed, you can ask for samples to check our quality. Samples are free.
Q5.When can I get the price after an inquiry?
A: We usually quote within 6 hours after receiving your inquiry. If you are in a hurry, please call us or note in your email so that we can give priority to your inquiry，Thank you.
Hot Tags: Efficient flat flexible rvvb cable, China, suppliers, manufacturers, factory, wholesale, cheap, non metallic sheathed cable, 2 Core Sheathed Cable, rubber insulated wire, Twin and Earth Cable, Flexible Sheath Cable, silicone rubber wire
