2 Core Rubber Cable
2 core rubber cable can withstand weather, oil / grease, mechanical and thermal stress.
Description
Model | HZ-07C | Brand | OEM |
Product name | 2 Core Rubber Cable | Type | LOW VOLTAGE, Rubber cable |
Application | Machine | Place of Origin | Zhejiang,China(Mainland) |
Cable | H05RN-F 3C*0.75/1.0/1.5mm2 | Voltage Rating | 450/750v |
Conductor | Bare Copper | Transport Package | Rolls,Wooden drum or according to your request. |
Jacket | PVC | certificated | CE ,VDE,ROHS,SGS |
Application and Features
The factory has more than 10 years of production experience and rich export experience in producing 2 core rubber cable. Provide OEM services according to official and legal authorization, strong technical support (technical data, drawings, etc.), strictly control the quality, and actively provide you with professional team cooperation services. Achieve fast delivery and feedback faster lead times than our competitors.
2 core rubber cable can withstand weather, oil / grease, mechanical and thermal stress. Its applications include handling equipment, mobile power supply, construction site, stage and audio-visual equipment, port area and dam, as well as drainage and water treatment, cold environment and harsh industrial environment.
Product
Technical Data
TYPE | Nominal Section (mm²) | Structure of Conductor Core No./Dia.（mm） | INSULATION THICKNESS (mm) | JACKET THICKNESS (mm) | OVERALL DIAMETER 0.15(mm) | Max.Conductor Resistance at 20℃ (Ω/KM) |
H03RN-F | 1/0.5 mm² | 16*0.2 | 0.6 | 0.6 | 3.4±0.15 | 39 |
1*0.75 mm² | 24*0.2 | 0.6 | 0.6 | 3.6±0.15 | 26 | |
H05RN-F | 2*0.75 mm² | 24/0.2 | 0.6 | 0.8 | 6.3±0.2 | 26 |
2*1 mm² | 32/0.2 | 0.6 | 0.8 | 6.7±0.2 | 19.5 | |
3*0.75 mm² | 24/0.2 | 0.6 | 0.9 | 6.8±0.2 | 26 | |
3*1 mm² | 32/0.2 | 0.6 | 0.9 | 7.2±0.2 | 19.5 | |
H05RN-7 | 1*1.5 mm² | 30/0.5 | 0.8 | 1.4 | 6.2±0.2 | 13.3 |
2*1.5 mm² | 30/0.25 | 0.8 | 1.5 | 9.3±0.3 | 13.3 | |
3*1.5 mm² | 30/0.25 | 0.8 | 1.6 | 10.1±0.4 | 13.3 | |
4*1.5 mm² | 30/0.25 | 0.8 | 1.7 | 11.1±0.4 | 13.3 | |
5*1.5 mm² | 30/0.25 | 0.8 | 1.8 | 12.2±0.4 | 13.3 | |
5*6 mm² | 84/0.30 | 1.0 | 2.5 | 19.1±0.6 | 3.3 |
Our Company
Packaging
FAQ
Q1.Are you a factory or a trading company?
A: We are a factory with more than 10 years of manufacturing experience.
Q2.Where is your factory?
A: Jiaxing City, Zhejiang Province, China.
Q3.What can you offer?
A: We produce all kinds of wires and cables, which can be customized according to your requirements.
Q4.What is the lead time for mass production?
A: It depends on the order quantity and product specification. Please contact us as soon as possible if necessary.
Q5.When can I get the price after an inquiry?
A: We usually quote within 6 hours after receiving your inquiry. If you are in a hurry, please call us or note in your email so that we can give priority to your inquiry，Thank you.
