Coaxial RG6 2C Power Cable
We can manufacture and supply coaxial cable, LAN cable, optical fiber cable and cable components.
Coaxial RG6 2C Power Cable
Application and Features
Our factory can professionally manufacture and supply coaxial cable, LAN cable and optical fiber cable. Our main products include coaxial cable (coaxial RG6 2C power cable, RG6, KX 7), optical fiber cable (incoming cable, ADSS, gyxtw, GYTS, gyxfty), LAN cable (cat 5E, Cat 6, cat 7).
In Hongzhou, quality always comes first. The company operates under the ISO 9001 quality management system, and our products have passed ROHS, CE, CPR and Anatel certification. In addition, we can provide free samples, free box design and OEM production. With advanced testing equipment, our experienced QC
The team ensures that each of our product lines meets specific standards for specific markets.
Our product coaxial RG6 2C power cable and most other products are exported to Europe, America, South America and Southeast Asia. More importantly, our company has been committed to developing customized cables according to customers' needs. We look forward to working with you for mutual benefit in the future.
Description
Model: Coaxial RG6 2C Power Cable
Specifications ： Custom cables and harnesses / OEM, ODM
Certification: UL, CSA, CE, VDE, SAA, CCC
Quality certificate: ISO9001, ISO13485, iatf16949, UL factory
Size range ： Thousands of different connectors are available.
colour ： According to customer requirements.
Application: Industrial / medical / Automotive
sample ： Samples are available for evaluation.
Quality Control ： Passed iso9001:2015 quality control system. All products are 100% tested before delivery.
Minimum order quantity: Sample orders / small orders are acceptable.
Delivery time ：Sufficient inventory and strong production capacity to ensure timely delivery.
pack ： Each bag of 100 / 200 / 300 / 500 / 1000 pcs is labeled and exported to standard cartons.
Application
Product
Technical Data
|
@ Frequency MHz |
dB/100 ft. (MAX.) |
dB/100 meters (MAX.) |
|
5 MHz |
0.58 dB |
2.65 dB |
|
55 MHz |
1.60 dB |
5.25 dB |
|
83 MHz |
1.95 dB |
6.40 dB |
|
187 MHz |
2.85 dB |
9.35 dB |
|
211 MHz |
3.05 dB |
10.00 dB |
|
250 MHz |
3.30 dB |
10.82 dB |
|
300 MHz |
3.55 dB |
11.64 dB |
|
350 MHz |
3.85 dB |
12.63 dB |
|
400 MHz |
4.15 dB |
13.61 dB |
|
450 MHz |
4.40 dB |
14.43 dB |
|
500 MHz |
4.66 dB |
15.29 dB |
|
550 MHz |
4.90 dB |
16.08 dB |
|
600 MHz |
5.10 dB |
16.73 dB |
|
750 MHz |
5.65 dB |
18.54 dB |
|
865 MHz |
6.10 dB |
20.01 dB |
|
1000 MHz |
6.55 dB |
21.49 dB |
Our Certificate
Our Workshop
Exhibition
Our Team
After-sales team
business team
design team
Operations team
Our Business Partner
Certification
TV EN50618
TV PV1-F
CE
SGS
SAA
ISO9001
Factory overview
Cargo Transportation
Hot Tags: coaxial rg6 2c power cable, China, suppliers, manufacturers, factory, wholesale, cheap
