22 Awg Single Core Wire
Application: Construction, Overhead, Underground, Industrial, Power Station, Computer
Insulation Material: Teflon
Material Shape: Round or Sector
Wire Core Material: Tinned Wire
Model: Teflon Wire
Colour: Red/Green/Blue/Black/White/as Request
Description
|
Model |
HZ-62A |
Brand |
OEM |
|
Product name |
22 awg single core wire |
Type |
Insulated |
|
Application |
Home appliance,lighting,heater,motor,generator |
Place of Origin |
Zhejiang,China |
|
Conductor Material |
Copper |
Rated Voltage |
450/750V |
| Insulation Material |
PVC |
Packing |
100/200/300 roll |
|
Color |
all colours |
Certificated |
ISO9001/VDE/CCC |
Application and Features
22 AWG single core wire is suitable for laying in pipes, or can be laid in the open air or buried in casings. It is not allowed to be directly installed in cable trays, buildings or containers.
22 AWG single core wire is applicable to the protective laying of instrument interior, lighting, drying room, production equipment and switchgear.
Performance:
Working voltage: 300/500v 450/750v
Insulation resistance: 10 GOM x cm
Minimum bending radius: 15 x cable diameter
Operation and installation: -5 ℃ to +80 ℃
Fixed installation: -40 ℃ to +70 ℃
Oil resistance, flame retardancy and extension flammability: IEC 60332.1/hd 405.2 and VDE 0207-4
Product
 |
 |
 |
 |
Technical Data
|
AWG Size
|
Conductor No./mm
|
Nom.O.D.(cm)
|
Nom.Insul.Thick.(cm)
|
Approx LBS/MFT
|
Ampacity@90℃
|
|
14
|
Solid
|
0.26
|
0.04
|
15
|
15
|
|
14
|
19/0.38
|
0.28
|
0.04
|
16
|
15
|
|
12
|
Solid
|
0.30
|
0.04
|
23
|
20
|
|
12
|
19/0.47
|
0.33
|
0.04
|
24
|
20
|
|
10
|
Solid
|
0.41
|
0.05
|
38
|
30
|
|
10
|
19/0.60
|
0.41
|
0.05
|
38
|
30
|
|
8
|
19/0.75
|
0.54
|
0.08
|
63
|
55
|
|
6
|
19/0.95
|
0.63
|
0.08
|
95
|
75
|
|
4
|
19/1.19
|
0.81
|
0.10
|
152
|
95
|
|
3
|
19/1.33
|
0.88
|
0.10
|
189
|
110
|
|
2
|
19/1.50
|
0.96
|
0.10
|
234
|
130
|
|
1
|
19/.0664
|
1.10
|
0.13
|
299
|
150
|
|
1/0
|
19/1.68
|
1.20
|
0.13
|
372
|
170
|
|
2/0
|
19/1.89
|
1.32
|
0.13
|
462
|
195
|
|
4/0
|
19/2.67
|
1.58
|
0.13
|
718
|
260
|
Our Team
After-sales team
business team
design team
Operations team
Our Business Partner
Certification
TV EN50618
TV PV1-F
CE
SGS
SAA
ISO9001
Factory overview
Cargo Transportation
FAQ
1. Are you a trading company or a manufacturer?
We are a factory.
2. Do you provide samples? Is it free or extra?
Yes, we can provide samples free of charge, but we don't pay the freight.
3. What about the delivery time?
Samples take 3-5 days, batch production takes 1-2 weeks, and the number of orders exceeds
4. Do you have a minimum order quantity limit for cable orders?
Low order quantity, usually 500m for large-size cables and 1km for small-size cables.
5. Can I print my logo on cable products?
yes. Please inform us formally before production and confirm the design according to our samples first.
6. Do you guarantee the product?
Yes, we provide a 2-5 year warranty for our products.
