Single Core Electrical Wire
Type: Insulated
Conductor Type: Stranded
Application: Overhead, Underground
Conductor Material: Aluminum
Sheath Material: PVC
Insulation Material: N/a
Description
Model | HZ-47A | Brand | OEM |
Product name | Single core electrical wire | Type | insulated |
Application | Other | Place of Origin | Zhejiang,China |
Conductor Material | Copper | Rated Voltage | 450/750V |
Jacket | PVC | Packing | Carton |
Color | Black, Red, Yellow, Blue or customized | Certificated | ROHS/UL/CCC/VDE/CCC/SGS/ISO9001:2008 |
Application and Features
Main features of single core electrical wire: uo/u is 450/750v, 300/500v, long-term allowable temperature of cable: 105, the allowable temperature of cable should not exceed 105 ℃, and the allowable temperature of other models should not exceed 70 ℃.
PVC single core electrical wire is a kind of high-quality and ideal cable. Its conductor is pure annealed copper wire, solid or stranded. These cables are used for general purposes, as building wires for power and lighting and control wires for electrical equipment, and are suitable for conduit and fixed protection installation. Cables can have flame retardancy, fire resistance and other properties.
Product
 |  |
 |  |
Technical Data
AWG Size | Conductor No./mm | Nom.O.D.（cm） | Nom.Insul.Thick.（cm） | Approx LBS/MFT | Ampacity@90℃ |
14 | Solid | 0.26 | 0.04 | 15 | 15 |
14 | 19/0.38 | 0.28 | 0.04 | 16 | 15 |
12 | Solid | 0.30 | 0.04 | 23 | 20 |
12 | 19/0.47 | 0.33 | 0.04 | 24 | 20 |
10 | Solid | 0.41 | 0.05 | 38 | 30 |
10 | 19/0.60 | 0.41 | 0.05 | 38 | 30 |
8 | 19/0.75 | 0.54 | 0.08 | 63 | 55 |
6 | 19/0.95 | 0.63 | 0.08 | 95 | 75 |
4 | 19/1.19 | 0.81 | 0.10 | 152 | 95 |
3 | 19/1.33 | 0.88 | 0.10 | 189 | 110 |
2 | 19/1.50 | 0.96 | 0.10 | 234 | 130 |
1 | 19/.0664 | 1.10 | 0.13 | 299 | 150 |
1/0 | 19/1.68 | 1.20 | 0.13 | 372 | 170 |
2/0 | 19/1.89 | 1.32 | 0.13 | 462 | 195 |
4/0 | 19/2.67 | 1.58 | 0.13 | 718 | 260 |
