12 Gauge Single Strand Electrical Wire
Type: Insulated
Conductor Type: Solid
Application: Underground
Conductor Material: Copper
Insulation Material: PVC
Material Shape: Round Wire
Description
|
Model |
HZ-16A |
Brand |
OEM |
|
Product name |
12 gauge single strand electrical wire |
Type |
Insulated |
|
Application |
Electrical wire, Building, construction, industrial |
Place of Origin |
Zhejiang,China |
|
Conductor Material |
Copper |
Rated Voltage |
300/500V 450/750V |
|
Insulation Material |
PVC |
Package |
Carton |
|
Color |
Up on request |
Certificated |
CE/ROHS/CCC/ISO9001 |
Application and Features
Advantages and disadvantages of single solid core wire
Advantages: small cross-sectional area ratio, not easy to be oxidized, resistant to short-circuit current impact, and relatively long service life.
Disadvantages: 12 gauge single strand electrical wire is relatively hard, and it is inconvenient to pull wires in some places. It is difficult to straighten after bending, and it is easy to damage wires after multiple bending.
Classification and color of single strand electrical wire
Single strand electrical wire includes bv wire, RV wire and BVV wire. BVR wire is a multi-core wire with soft material and many small copper wires twisted together.
The common colors of single core wires are: red, yellow, blue, green, black, white, two colors (yellow, green), brown.
Product
 |
 |
 |
 |
Technical Data
|
AWG Size
|
Conductor No./mm
|
Nom.O.D.(cm)
|
Nom.Insul.Thick.(cm)
|
Approx LBS/MFT
|
Ampacity@90℃
|
|
14
|
Solid
|
0.26
|
0.04
|
15
|
15
|
|
14
|
19/0.38
|
0.28
|
0.04
|
16
|
15
|
|
12
|
Solid
|
0.30
|
0.04
|
23
|
20
|
|
12
|
19/0.47
|
0.33
|
0.04
|
24
|
20
|
|
10
|
Solid
|
0.41
|
0.05
|
38
|
30
|
|
10
|
19/0.60
|
0.41
|
0.05
|
38
|
30
|
|
8
|
19/0.75
|
0.54
|
0.08
|
63
|
55
|
|
6
|
19/0.95
|
0.63
|
0.08
|
95
|
75
|
|
4
|
19/1.19
|
0.81
|
0.10
|
152
|
95
|
|
3
|
19/1.33
|
0.88
|
0.10
|
189
|
110
|
|
2
|
19/1.50
|
0.96
|
0.10
|
234
|
130
|
|
1
|
19/.0664
|
1.10
|
0.13
|
299
|
150
|
|
1/0
|
19/1.68
|
1.20
|
0.13
|
372
|
170
|
|
2/0
|
19/1.89
|
1.32
|
0.13
|
462
|
195
|
|
4/0
|
19/2.67
|
1.58
|
0.13
|
718
|
260
|
Our Company
Packaging
FAQ
1. Who are we?
We are based in ZheJiang, China, start from 1984, sell to Domestic Market(62.50%),Southeast Asia(12.50%),Africa(10.00%),Mid East(8.00%),South America(5.00%),Western Europe(1.00%),Oceania(1.00%). There are total about 11-50 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Electric Wire or Cable
4. Why should you buy from us not from other suppliers?
We, with good reputation, have a wide business scope and have established regular business relations with many suppliers. Pure copper, new materials, short delivery, competitive price, the most important is the only one which worked with CCTV in 2014 years
All of our products have CE, ISO9001, CCC, RoHS etc..and we can apply other certifications which customers require.
5. What services can we provide?
7days * 24hours sales team service, respond customers' question within one hours.
Formal quotation can sent to customers' within 7 hours.
