Single/Multi Core Ultra Flexible Thin Heating PVC Insulated Copper Electrical Wire

It is used for rated lighting, electronic equipment, instruments and communication equipment, and can be used under 450 / 750V.

Send Inquiry

Our company will spare no effort to produce the most advanced and applicable professional Cat5e Outdoor Cable, Lan Cable, 22 gauge insulated copper wire with the latest concepts in the industry and in response to the needs of our customers. We work with our partners to create shared value, contribute to social progress, and ensure the long-term success of our company. At present, our products have formed a multi-species serialized product structure system, which can meet the actual needs of different customer groups. The company will devote itself to pouring its own wisdom into the industry, so that the products produced by the industry will serve the society well. Under the guidance of the "market orientation, brand development" strategic policy, the company has achieved steady development, insists on introducing technology and capital investment, attaches importance to the training of talents, builds a group of comprehensive talents, and also lays a solid foundation for product quality and customer service basis!

Description

Model	HZ-01B	Brand	OEM
Product name	PVC Sheathed welding cable	Type	LOW VOLTAGE
Application	Industrial	Place of Origin	Zhejiang,China(Mainland)
Conductor	Copper Core	Voltage Rating	250V
Color	Black or as required	Transport Package	Carton
Jacket	Rubber	certificated	CCC, CE, ISO

Application and Features

PVC Sheathed welding cable is usually a bundle of wire with a length of 100m (plus or minus 2-3m), and the specification of ordinary wire: 1m2 / 1.5m2 / 2.5m2 / 4m2 / 6m2 / 10m2; Difference between BV and BVR: BV is a single strand line, BVR is a multi strand line, and the price of BVR exceeds about 5% of BV. It is used for rated lighting, electronic equipment, instruments and communication equipment, and can be used under 450 / 750V.

PVC Sheathed welding cable is manufactured according to relevant standards: IEC60502, GB5023, BS5467, BS6622, ASTM JB8734 or your requirements.

The company has been using advanced process equipment, strong technical R & D team, strict quality assurance system and perfect testing means, competitive price, high-quality products and excellent after-sales service, and enjoys a good reputation at home and abroad.

Product

Technical Data

Conductor Nominal Section ( mm2)	Conductive Core	Thickness of Section Sheath (mm)	Average Outer Diameter (mm2)		20oC Conductor Resistance≤(Ω/km)		Reference Weight(kg/km)

	Number/Diameter of Core(mm)		Min	Max			YH	YHF

10	322/0.20	1.8	7.5	9.7	146	153.51	146	153.51
16	513/0.20	2	9.2	11.5	218.9	230.44	218.9	230.44
25	798/0.20	2	10.5	13	316.6	331.15	316.6	331.15
35	1121/0.20	2	11.5	14.5	426	439.87	426	439.87
50	1596/0.20	2.2	13.5	17	592.47	610.55	592.47	610.55
70	2214/0.20	2.4	15	19.5	790	817.52	790	817.52
95	2997/0.20	2.6	17	22	1066.17	1102.97	1066.17	1102.97
120	1702/0.30	2.8	19	24	1348.25	1392.55	1348.25	1392.55
150	2135/0.30	3	21	27	1678.5	1698.72	1648.5	1698.72
185	1443/0.40	3.2	22	29	1983.8	2020.74	1983.8	2020.74

Our Company

Packaging

7486(1)

FAQ

1.What certificate did you get?

We have CCC, CE, VDE, IMQ and other certificates.

2.When is your delivery time?

Our delivery time is about 3-4 weeks after confirming payment, depending on the quantity of the order.

3.What can you offer?

We produce all kinds of wires and cables, which can be customized according to your requirements.

4.Can we get samples before ordering?

Yes, we are willing to arrange samples for you.

5.When can I get the price after an inquiry?

We usually quote within 6 hours after receiving your inquiry. If you are in a hurry, please call us or note in your email so that we can give priority to your inquiry.

With our strong economic strength and adherence to the principle of honesty, we have gained the trust of our customers and a good reputation in the Single/Multi Core Ultra Flexible Thin Heating PVC Insulated Copper Electrical Wire industry. With factory control standards that are superior to domestic and international standards, it meets customers' expectations and requirements for product quality. To We wish to work with you and seek common development.
