4mm flat twin and earth

Type: Insulated
Conductor Type: Stranded
Application: Overhead, Underground
Conductor Material: Copper
Sheath Material: PVC
Insulation Material: PVC

Send Inquiry

Description

Model	HZ-03C	Brand	OEM
Product name	Flat Cable with Earth	Type	Twin and earth cable
Application	Heating, underground, building	Place of Origin	Zhejiang,China(Mainland)
Cable	H05VV-F 3C*0.75/1.0/1.5mm2	Voltage Rating	250V
Color	Red, blue, black, gray or as needed	Transport Package	Color box, plastic woven bag, carton, as required
Length	100M / 100y / or as required	certificated	CCC,CE ,VDE,ROHS,SGS

Application and Features

4mm Flat twin and earth wire is composed of stranded bare copper wire, which can also be used according to your requirements

PVC insulated PVC sheathed, and passed GB 18380.1 vertical burning test. The insulation thickness of the conductor shall be uniform to ensure that it is easy to peel and cut, and resistant to acid, alkali, oil, moisture and fungi, in accordance with ROHS.

Flat twin and earth are available in a variety of colors. Oem/odm services can be provided, with reasonable price, reliable quality and friendly service. We look forward to working with you!

Product

Technical Data

Nominal Cross Section	Wire Diameter	Thickness of Insulation	Thickness of Insulation	Overall diameter
mm2	mm	mm	mm	Max.mm
2×1.5	7/0.51	0.7	0.9	5×8.1
2×2.5	7/0.66	0.8	1.0	5.9×9.5
2×4	7/0.83	0.8	1.0	6.4×10.7
3×1.5	7/0.51	0.7	0.9	4.8×10.5
3×2.5	7/0.66	0.8	1.0	5.7×12.6
3×4	7/0.83	0.8	1.1	6.7×15.1

Our Company

Packaging

FAQ

1: when can I get the price?

We usually quote within 6 hours after receiving your inquiry. If you are very anxious to get the price, please call us or tell us in your email so that we can

Give priority to your inquiry.

2. How can I get samples to check your quality?

After the price is confirmed, you can ask samples to check our quality. Samples are free, but freight is required.

3. How long can I expect to get samples?

After you pay the freight and send us the confirmation documents, the samples will be ready for delivery within 3-7 days.

The samples will be sent to you by express and arrive within 3 ~ 5 days.

4. What products do you produce?

Wires and cables; power cord; Communication cable; Coaxial cable, etc.

5. What are your terms of payment?

T/T or L/C.

Hot Tags: 4mm flat twin and earth, China, suppliers, manufacturers, factory, wholesale, cheap, house wiring cable, 6mm twin and earth cable, metal sheathed electrical wire, 2 5 twin and earth, PVC Sheathed Cable, Efficient Bvvb Flat Cable
