Thhn General Cable

Product Description

General Cable is a trusted and reliable product that requires careful handling to ensure its optimal performance and longevity. This thhn general cable is designed for a wide range of applications, including power distribution, control systems, and communication networks. It is known for its high-quality construction, durability, and resistance to damage, making it a favorite among professionals across various industries.Overall, General Cable is a high-quality product that can be trusted to deliver superior performance, durability, and versatility. However, to ensure its optimal performance and longevity, it is important to follow the recommended guidelines for installation and use.

---

Our advantage

Superior performance

General Cable is designed to provide consistent and reliable performance, even under challenging conditions.

Durability

The cable is constructed using high-quality materials that make it resistant to damage, ensuring a longer lifespan.

Versatility

General Cable is suitable for a wide range of applications, making it a versatile choice for professionals across different industries.

Cost-effective

Despite its many benefits, General Cable is an affordable option that offers excellent value for money.



Product Size

Item Spec. AWG	Nominal Cross Section	NO./Diameter Of Conductor mm	Insulation Thicknese mm	Jacket Thicknese mm	Max.Outer Diameter mm	Ref.Weight kg/km
20	0.519	1/0.813	0.4	0.12	2.0	7.07
18	0.823	1/1.02	0.4	0.12	2.2	10.94
16	1.31	1/1.29	0.4	0.12	2.5	16.48
14	2.08	1/1.63	0.4	0.12	2.8	23.17
16	1.31	7x0.49	0.4	0.12	2.8	17.95
14	2.08	7x0.62/19x0.36	0.4	0.12	3.2	23.8



When using General Cable, it is important to take note of the following guidelines:

1. Make sure that the thhn general cable is stored in a cool, dry place to protect it from moisture and corrosion.

2. Avoid bending the cable at sharp angles or excessively twisting it, as this can damage the insulation and result in poor performance.

3. When installing the thhn general cable, use appropriate connectors and fasteners and make sure they are properly secured.

4. When running the cable, make sure it is not exposed to sharp edges or abrasive surfaces that could damage the insulation.

5. Never use the cable for applications that exceed its specified voltage or current rating.

---

OUR PRODUCTS



Multi-core Flexible Cable

Single Core Wire

Twin Flat Cable

Twin With Earth Cable

Welding Cable

Twin Flat Flexible Cable

0.6/kv pvc/xlpe Cable

NR Rubber Flexible Cable

FAQ

Will #2 copper THHN be a sufficient cable to run to the subpanel?

The adequacy of a particular cable depends on various factors, such as the distance of the subpanel from the main panel, the voltage and amperage requirements of the subpanel, the load to be connected, and the local electrical codes and regulations. It is advisable to consult a licensed electrician or a qualified engineer to determine the proper cable size and type for your specific application.
